Existent Gum Evaporation Bath

Description

Electrically heated baths for determining existent gum in aircraft turbine fuels by steam-jet evaporation and in motor and aviation gasolines by air-jet evaporation. Fully insulated, aluminum block design assures safe, efficient high temperature operation. Equipped with air/steam pressure regulator with gauge and a digital flowmeter for adjusting air flow per ASTM specifications. Stainless steel jets deliver air or steam flow to the test wells through removable brass conical adapters. Microprocessor PID control provides quick temperature stabilization without overshoot and the bath is protected by an over-temperature control circuit that interrupts power should the bath temperature exceed a programmed cut-off point. Dual LED displays provide actual and setpoint temperature values in °C/°F format.

Features

Conforms to ASTM D381 and related specifications
Choice of three-unit and six-unit models
Safety top assembly allows for easy positioning and connection of all conical adapters to the bath
Digital flowmeter for accurate and precise air flow measurement
Available with built-in steam superheater
Microprocessor programmable high accuracy temperature control
Built-in pressure regulators and air flowmeters

Specification

Conforms to the specifications of: ASTM D381; IP 131; IP 540; ISO 6246; DIN 51784; FTM 791-3302; NF M 07-004

Testing Capacity: K33900: 6 sample beakers

K33780 and K33781: 3 sample beakers

Maximum Temperature: 475°F (246°C)

Temperature Control Stability: ±1°F (±0.5°C)

Bath Configuration: machined aluminum block with multiple cartridge heaters

Heater Range:

K33900: 0-3000W
K33780 and K33781: 0-1500W

Superheater: (Model K33900 only)

Superheating chamber and condensate trap constructed of stainless steel
Solid state thermoregulator (0-550°F) Heater Range: 0-3000W

Steam Generator: Output: 54.1 lbs steam/hr at 212°F
